MEMS 光开关矩阵模块 24×12
光路示意图
尺寸示意图
管脚定义
|
Pin number |
Pin definition |
Signal direction, type |
Function description |
|
1 |
NC |
|
dangling |
|
2 |
NC |
|
dangling |
|
3 |
VCC |
Power |
Power supply, DC 5V, 2A |
|
4 |
VCC |
Power |
Power supply, DC 5V, 2A |
|
5 |
GND |
Power |
GND |
|
6 |
GND |
Power |
GND |
|
7 |
NC |
|
dangling |
|
8 |
NC |
|
dangling |
|
9 |
TXD |
Output |
Serial port data transmitter (LVTTL level serial port). |
|
10 |
RXD |
Input |
Serial data receiving terminal (LVTTL level serial port). |
|
11 |
NC |
|
dangling |
|
12 |
NC |
|
dangling |
|
13 |
NC |
|
dangling |
|
14 |
NC |
|
dangling |
|
15 |
NC |
|
dangling |
|
16 |
NC |
|
dangling |
|
Model number |
HC-MEMS 24X12 |
|
Operating wavelength |
1310/1550nm |
|
Insertion loss |
≤3.0dB |
|
Return loss |
≥45dB |
|
crosstalk |
≥50dB |
|
Switch time |
≤30ms |
|
Transmit optical power |
≤23dBm |
|
Fiber type |
SM-9/125 |
|
Optical type |
LC/PC |
|
Fiber length |
0.6m |
|
Control interface |
UART |
|
Operating voltage |
DC5V |
|
Module power consumption |
≤10W |
|
Operating temperature |
-5℃ ~ +60℃ |
|
Storage temperature |
-40℃ ~ +85℃ |
|
Module size |
320X200X18mm |
