Features:
l Lab-Grade Testing Solution
l Multi-Standard Compatibility
l Accurate Path Loss Simulation
l Mobility &Handover Simulation
l Bi-Directional RF Signal Support
Independent Multi-Channel Control
Specification:
|
Frequency Range |
10MHz-6GHz |
100MHz—40GHz |
|
Attenuation |
0-127 dB,1dB/0.5dB/0.25dB per step |
0-60 dB,1dB per step |
|
VSWR(Avg.) |
≤1.5 |
≤2 |
|
Attenuation Accuracy |
0-31≤±0.25dB;32-100≤±0.5dB |
0-31≤±0.5dB;32-60≤±0.9dB |
|
Insertion Loss |
0.7GHz≤5.3dB,3GHz≤6.8dB,6GHz≤11.5dB |
28GHz≤13dB,39GHz≤15dB |
Ordering Information: 1CH,4CH,8CH,16CH,24CH,48CH,etc.
